Portable Utility Lights
4 Sources of Light Sources
• High light output
• Weatherproof aluminum die-
cast light heads
• 500 Watt quartz bulbs
(included).
• Uses compact, low energy use
• Long life 55 Watt Fluorescent
bulbs (included)
• Shade remains Cool-to-the-
Touch.
Light Selection Chart & Illumination Levels
6 Types of Bases and Mounts
Pedestal Base
• 16 gauge round steel tube
construction
• Height adjustable from
5’- 6” to 8’- 6” high
• 18” heavy duty steel base
Cart Base
• 16 gauge round steel
tube construction
• Height adjustable from
5’ to 8’ high
• 10” diameter wheels
Floor Base
• 12 gauge steel base
• Handle included
• Base covers 16”
diameter area
Clamp-On Mount
• Clamp secures
light head to most
surfaces up to 3”
Magnet Mount
• 210 lb. magnetic strength
• 1/4” steel arm
• Extends 6” from mounting
surface
Tripod Base
• 20 gauge round steel tube
construction
• Height adjustable from 3’ to
6’- 6” high
• Base covers 46” diameter
area
ATTENTION
Fluorescent and HID lamps contain mercury. Dispose of these lamps according to local, state, or federal laws. For further
information on local, state, or other requirements for disposal of mercury-containing lamps, see
http://www.lamprecycle.com.
Quartz Halogen
Fluorescent
• Longest Lamp Life
• Lowest energy usage per lumens
produced.
• 12 Watt LED bulbs (included)
• Shade remains Cool-to-the-Touch.
LED 1 & 2
LIGHT SOURCE:
QUARTZ
HALOGEN FLUORESCENT LED LED 37
# OF LIGHT HEADS
1
2
1
2
1 2 1 2
MAX. WATTAGE
500 1,000 55 110 12 24 37 74
MAX. LUMENS
11,000 22,000 3,000 6,000 960 1,920 2,373 4,746
AVG. BULB LIFE (HRS.)
2,000
10,000
50,000
>30,000
WIRE GUARD INCLUDED
Yes
Yes
Yes
No
BULB INCLUDED
Yes
Yes
Yes
Yes
LIGHT SOURCE ILLUMINATION LEVELS
Measured Footcandles & Distance
from Light Source (open area)
5’ ft.
74.4 137.3 20.0 35.8 224.5 456.8 448.1 896
10’ ft. 36.1 65.9 8.7 14.8 121.4 258.8 299 598
20’ ft. 13.2 24.6 3.1 5.1 29.0 64.0 71 142
30’ ft.
6.6 12.3 1.7 2.5 14.2 31.4 34 68
PED
CRT
TRI
FLR
LED-1
LED-2
FL-1
FL-2
CLP
MAG
QH-1
QH-2
Task Lighting...
When &
where you
need it!
LED 37
LED-37
LED-37-2
• 30,000+ hour lamp life
• Safety glass front lens cover
• NEMA 4 rated enclosure
• Can be used with pedestal, cart,
and tripod mounts only.
• Compliant with RoHS 2 Directive
(2011/65/EU).
