Industrial Mounted Workstation Fans
Features
• Pull chain switch
• Head rotates 360° vertically and horizontally
• Coated steel guards
• SJT type 3 conductor, 10’ long cord
• Steel hub/spider aluminum paddle blades
• Meets OSHA standards / 1 Year limited warranty
• Imported to TPI specifications
Motor Specifications
•3-Speed
•1-Phase, 120V
•5/16 Shaft
• Sleeve bearing
• Totally enclosed, permanently lubricated
• Frame size: 42
Note: Mount with one bolt or lag screw to walls, ceilings, work benches, machines or any surface.
Standard Models
Pipe Mount Adaptor
Workstation Oscillating Office Fans
• 3-speed oscillating fans with push button controls
• 3 conductor SPT cord & plug
• White powder coated wire mesh guards
• White plastic housing and blade
• Stand fan extends to 40” height
• Meets OSHA standards / 1 Year limited warranty
• Imported to TPI specifications
Standard Models
Features
STAND FAN DESK FAN
• 3-Speed
• 120V
• Sleeve bearing
• 1-Phase
• Open ventilated
• Permanently lubricated
Standard Models
Motor Specification
• Rotary switch
• SJT type cord - 3 conductor - 7’ long
• Aluminum blade
• Coated steel guards with retaining clips
• Meets OSHA standards / 1 Year limited warranty
• Imported to TPI specifications
Features
TPI Commercial Workstation & Floor Fans
CF-20
CU-20
Units should be used in clean, dry, commercial applications.
Note: Photograph is a representation of stocked models. Actual model may vary in appearance.
FAN
SIZE
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MOTOR
HP
CFM / RPM DIMENSIONS MAX
AMPS
WT.
(LBS)
LIST
HIGH MED LOW “H” “W” “D”
12” 07986002 U-12-TE 1/12 900 /
1590
600 /
1380
500 /
1080 15-1/4” 14-1/2” 9-1/2” 1.1 13
154
18” 07972802 U-18-TE 1/8 2500 /
1660
2200 /
1550
1980 /
1370 21-1/2” 20-1/2” 10-1/2” 2.2 20
190
24” 08540702 U-24-TE 1/8 2900 /
1634
2600 /
1484
2100/
1200 27” 26” 10-1/2” 2.4 23
356
PIPE
DIAMETER
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
LIST
1”
08512402 PM-1
52
1-1/2” 08512502 PM-1.5
57
2”
08512602 PM-2
63
2-1/2” 08512702 PM-2.5
68
3”
08512802 PM-3
75
SIZE MFG CATALOG
NUMBER
MFG MODEL
NUMBER
FAN
TYPE SPEEDS CFM
HIGH
AMPS
HIGH
WT.
(LBS)
LIST
12”
08513002
ODF-12 DESK 3 1200 0.4 5.4
74
16”
08513102
ODF-16 DESK 3 2100 0.5 8.5
86
16”
08513202
OSF-16 STAND 3 2100 0.5 15.5
109
MFG CATALOG
NUMBER
MFG MODEL
NUMBER SIZE
TYPE
MOTOR
HP
CFM
MAX
AMPS
WT.
(LBS)
LIST
HIGH
MED
LOW
08723002
CF-12
12"
FLOOR
1/12
1050
875
750
0.6
10
86
08723102
CF-18
18"
FLOOR
1/5
1600
1350
1380
1.4
16
107
08706502
CF-20
20”
FLOOR
1/5
1725
1600
1480
1.9
18
148
05233302
CU-20
20” WORKSTATION 1/5
1725
1600
1480
1.9
18
177
