Industrial Workstation Floor Fans
• Sleeve bearing
• Totally enclosed
• 1-Phase, 120V
• 3-Speed
• Permanently lubricated
• Frame size: 42
• 5/16 Shaft
• Rotary switch
• Head tilts 360°
• Coated steel guards
• SJT type 3 conductor, 10’ long cord
• Steel hub/spider aluminum paddle blades
• Meets OSHA standards
• 1 Year limited warranty
• Imported to TPI specifications.
Features
Motor Specifications
Standard Models
HIGH STAND
FLOOR
MODEL
Corrosion Resistant Industrial Workstation Fans
• Pull chain switch
• Head tilts 360°
• FDA white coated steel guards
• SJTW type 3 conductor, 10’ long cord
• Steel hub/spider aluminum paddle blades
• Corrosion resistant motor and switch
• Meets OSHA standards / 1 Year limited warranty
• Made in U.S.A. with domestic and foreign components.
Features
• Sleeve bearing
• Totally enclosed
• 1-Phase, 120V
• 3-Speed
• Permanently lubricated
• Frame size: 42
• 1/2” Shaft
• Sealed electrical enclosure
Motor Specifications
HIGH STAND
WALL/CEILING
MODEL
FLOOR MODEL
Standard Models
*Made in U.S.A. with domestic and foreign components.
SIZE
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
FAN
TYPE
MOTOR
HP
CFM / RPM
DIMENSIONS MAX
AMPS
WT.
(LBS)
LIST
HIGH
MED
LOW “H” “W” “D”
12” 07986102 F-12-TE
FLOOR
MODEL
1/12 900 / 1590 600 / 1380 500 / 1080 15-1/4” 14-1/2” 9-1/2” 1.1
13
148
18” 07972902 F-18-TE
1/8 2500 / 1660 2300 / 1550 2000 / 1370 20-1/2” 20-1/2” 10-1/2” 1.5
20
185
24” 08528502 F-24-TE
1/8 2900 / 1634 2600 / 1484 2100 / 1200 26” 26” 10-1/2” 2.4
23
342
18” 07973002 F-18H-TE* HIGH
STAND
1/8 2500 / 1660 2300 / 1550 2000 / 1370 53” 25” 27” 2.2
27
269
24” 08540602 F-24H-TE*
1/8 2900 / 1634 2600 / 1484 2100 / 1200 53” 30” 27” 2.4
30
450
SIZE
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
FAN
TYPE
MOTOR
HP
CFM / RPM
DIMENSIONS MAX
AMPS
WT.
(LBS)
LIST
HIGH MED LOW “H” “W” “D”
18” 08763202 F-18-CR
FLOOR
MODEL
1/8 2500 / 1660 2300 / 1550 2000 / 1370 20-1/2” 20-1/2” 10-1/2” 1.5 20
387
24” 08763502 F-24-CR
1/8 2900 / 1634 2600 / 1484 2100 / 1200 26” 26” 10-1/2” 2.4 23
443
18” 08763302 F-18H-CR
HIGH
STAND
1/8 2500 / 1660 2300 / 1550 2000 / 1370 53” 25” 27” 2.2 27
515
24” 08763602 F-24H-CR
1/8 2900 / 1634 2600 / 1484 2100 / 1200 53” 30” 27” 2.4 30
554
18” 08763102 U-18-CR WALL/CEILING
MODEL
1/8 2500 / 1660 2300 / 1550 2000 / 1370 21-1/2” 20-1/2” 10-1/2” 2.2 20
387
24” 08763402 U-24-CR
1/8 2900 / 1634 2600 / 1484 2100 / 1200 27” 26” 10-1/2” 2.4 23
443
