Loading Dock Lights - Fully Assembled Standard Duty Loading Dock Arms
(Light Head and Arm Bolted Together and Shipped in One Carton)
Standard Models (120 V)
Ceiling Mounted Incandescent Flex Arm
• Flexible elastomer arm moves when hit and then returns light to original
position
• Ceramic socket will accept incandescent bulbs, R-40 or PAR bulbs up to 300W
• On-off toggle switch on light head
Features
Standard Models
Light Head Accessories
LG-1
Standard Models
Note: Lamp guards are included with every dock light fixture.
DLGS is shown with QH light head and 24” dock arm (sold separately)
*Bulb not included.
Incandescent
Quartz
Fluorescent
Note: Made in U.S.A. with domestic and foreign components
DLGS
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
ARM
LENGTH
# OF
ARMS
MAX
WATTS
WT.
(LBS)
LIST
INCANDESCENT
04466502
DKL-40VA-A
40”
2
300
14
201
04466602
DKL-60VA-A
60”
2
17
242
QUARTZ HALOGEN
04467102 DKL-40VA-QH-A 40”
2
500
15
242
04467202 DKL-60VA-QH-A 60”
2
18
281
LED
04708302
DKL-40VA-LED 40”
2
12
15
402
04708402
DKL-60VA-LED 60”
2
18
443
FLUORESCENT
04850302 DKL-40VA-FL-A 40”
2
55
15
305
04850402 DKL-60VA-FL-A 60”
2
18
330
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
ARM LENGTH WATTS
VOLTS
MAX
LUMENS
AVE. BULB
LIFE (HRS)
WT.
(LBS)
LIST
03854002
DKL-25-FLX
25”
300
120
3,700
2000
7
213
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
WATTS
USED WITH
WT.
(LBS)
LIST
03313222
LG-1
Lamp Guard
-
INC, LED, or FL Fixtures
2
39
04887402
DLGS Light Head Guard (Small)
-
LED-37
.5
45
04887502
DLGL Light Head Guard (Large)
-
LED, FL, QH
1
55
04850502 SSE-55
Fluorescent Bulb
55
ALL FL Light heads
1
54
04708502 LED-12
LED Bulb
12
ALL LED Light heads
1
186
