Machine Tool Lights
Water Resistant Fluorescent Tube Lights
Remote Ballast
with Cordset Internal Ballast
with Cordset
Remote Ballast
Features
• ETL C/US Listed for NEMA Type 13 applications - oil / water / coolant spray areas (not submersible)
and dusty atmospheres.
• Available with a durable, lightweight, economical, shatter resistant polycarbonate tube housing
• Model 21-TLP-IB-C includes a remote ballast, cordset, and on/off switch
• Stainless steel mounting hardware and fluorescent bulb are included
• 8’ long, 18/3 SJTOW cord with NEMA 5-15 plug on models with cords
• EOB units with internal ballast are factory wired for 120V w/ 8’ long cordset. Units can be field
converted for direct wiring for 90V to 277V. Terminal block provided for easy wire installation.
• Made in U.S.A.
Standard Models
Accessories - Replacement Lamps
* Includes 2 ft. lead wires
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION WATTS VOLTS LUMENS OVERALLLENGTH
TUBE
MATERIAL
BALLAST
INCLUDED
WT.
(LBS) LIST
02823200 21-TLP-IB-C REMOTE BALLASTWITH CORDSET 36 120V 2900 21” Polycarbonate Yes 10 522
04829502 29-TLP-EOB-C INTERNAL BALLASTWITH CORDSET 36 90 to 277V 2900 29” Polycarbonate Yes 7 442
04843402 29-TLP-A REMOTE BALLAST 50 120V 4300 29” Polycarbonate Yes 7 469
04829302 23-TLP-24VDC INTERNAL BALLAST 18 24VDC* 1250 23” Polycarbonate Yes 6 410
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION USED WITH WT.
(LBS) LIST
03103302 TL-RB-18 Fluorescent Replacement Bulb, 18W, PL-L All 18 Watt Models 1 62
03100802 TL-RB-36 Fluorescent Replacement Bulb, 36W, PL-L All 36 Watt Models 1 66
03108202 TL-RB-50 Fluorescent Replacement Bulb, 50W, PL-L All 50 & 100 Watt Models 1 74
