Industrial Ceiling Fans
Commercial Grade
Industrial Grade
Heavy Duty Grade
• Assembly required
• 30” lead wires
• 1 year limited warranty
• Fully assembled except blade bolt down
• 3 conductor cord, 30” long with plug
• Permanently lubricated
• 3 year limited warranty
• Fully assembled except blade bolt down
• 3 conductor cord, 30” long with plug
• Permanently lubricated
• 6 year limited warranty
• All metal construction, white epoxy finish
• 24” down rod with safety cable
• Mounts to 3/8” diameter steel J-hook
• 18 pole (motor), 115V, 1-Phase, capacitor type, impedance
protected motor with sealed ball bearings
• Imported to TPI specifications
Features
Standard Models
Solid State Controls (120 & 277V Models)
Options
* 277 volt, commercial, and reversing models have lead wires instead of cordset. 36” down rod available for additional charge.
Portable 18” Self Contained Power Mister
Motor Specification
• 1-Phase, 120 Volt
• Totally enclosed
• Permanent split capacitor
• 1-Speed, 1/8 HP
• Sleeve bearing
• Permanently lubricated
• Toggle Switch - fan only or fan & mist
• SJT type cord - 3 conductor - 18’ long with GFCI plug
• 18” Aluminum blade
• Spiral front and rear wire guards
• 85 PSI diaphragm pump
• Meets OSHA standards / 1 year limited warranty / Made in U.S.A.
Features
SELF CONTAINED MISTING SYSTEM WITH WATER PUMPED
FROMA 10 GALLON TANK OR VESSIL.
Standard Models
18” Fan & Pump Lid for 10gal. Tank
PM-18FO
PM-18S
PM-18C
Note: Tank lid not included.
Note: Photograph is a
representation of stocked models.
Actual model may vary in appearance.
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
TYPE
LIST
08512202
HR-GUARD
FOR 56” MODELS
1006
08504202
Suffix - X3
36” DOWN ROD OPTION
+45 Adder
GRADE
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
TYPE
SIZE VOLTS CFM RPM AMPS
WT.
(LBS)
LIST
Commercial
08529602
CHR-56*
Down Draft
56”
120
19000 320
0.6
15
182
Industrial
07979902
IHR-48
Down Draft
48”
120
17100 320
0.53
14
245
Industrial
07971502
IHR-56
Down Draft
56”
120
21000 310
0.6
15
258
Industrial
07980002
IHR-56R*
Reversible
56”
120
21000 310
0.55
14
263
Industrial
08008902
IHR-56-277V*
Down Draft
56”
277
21000 310
0.3
16
263
Water and Dust Resistant Models
Heavy Duty
08540802
HDHR-56WR Down Draft
56”
120
27500 320
1.1
17
362
Heavy Duty
08540902
HDHR-60WR Down Draft
60”
120
47000 320
0.8
21
408
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
WT.
(LBS)
LIST
08555202
PM-18FO
28
952
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
FAN
SIZE
TYPE
MOTOR
HP CFM AMPS WT.
(LBS)
LIST
08554702 PM-18S 18” HAND CARRY 1/8 2500 2.2 30
1111
08554902 PM-18C
CART
76
1413
08760702 NK-PM18 ---
REPLACEMENT NOZZLE KIT
26
MFG CATALOG
NUMBER
MFG MODEL
NUMBER VOLTS MAX
AMPS
VARIABLE CONTROL
KNOB
REVERSING
SWITCH
MAX #
OF FANS USE WITH CEILING FAN MODEL
LIST
07976302
KBWC-13K 120
3
YES; W/3” X 5”
ALUMINUM PLATE
(FITS 2” X 4” OPENING)
No
1-2 CHR-56, IHR-48/56, HDHR-56/60-WR
48
07976402
KBWC-15 120
5
3-5 CHR-56, IHR-48/56, HDHR-56/60-WR
114
07994102
KBWC 120
10
6-10 CHR-56, IHR-48/56, HDHR-56/60-WR
166
08666802 KBWC-155K 120
5
Yes
3-5
IHR-56R
153
08526502 KBWC-310K 277
10
No
6-10
IHR-56-277V
319
