Electric Infrared Heating Controls - FPC Control Panels

Pre-Wired Contactor Panels

FPC2120

• Factory pre-wired for quick installation,

with the following optional equipment:

Snow & Ice Detector (APS-3C)

Single & Two-Stage Thermostats

Two-stage thermostats require a

minimum 2-contactors.

Note: Contact factory for 3R, 4, 4X, & NEMA 12 “special” built models.

• Step-down transformer and secondary

fusing for 24V or 120V control circuit.

• 3-Phase load rated.

• Fuses are NOT included.

• NEMA 1 Enclosures.

• Max 50-Amp branch circuit fusing.

• Made in U.S.A.

IMPORTANT FUSING INFORMATION

Fuses are NOT included since panels can be used with various infrared heat sources. Quartz

Lamp Heat Sources: Use FRS-600V (or equal) “Time Delay” fuses; Class RK-5. Quartz Tube &

metal Sheath Heat Sources: Use KTS-R 600V (or equal) “Fast Acting” fuses; Class RK-1. Fuse

circuits as close to calculated load as possible. Circuits less than 35 Amps will require the use of

fuse reducers. *One heater only per circuit.

Standard Models

120-V CONTROL SYSTEM 24-V CONTROL SYSTEM

MAX

AMPS VOLTS

CABINET SIZE (IN.)

WT.

(LBS)

LIST

MFG

CATALOG

NUMBER

MFG

MODEL

NUMBER

MFG

CATALOG

NUMBER

MFG

MODEL

NUMBER

DEPTH WIDTH HEIGHT

04459902

FPC8110

04864302

FPC8210

50

208

6.75

16

24

52

2009

04460002

FPC2110

04864402

FPC2210

240

04460102

FPC7110

04864502

FPC7210

277/480

2163

04460202

FPC4110

04864602

FPC4210

480

1957

04460302

FPC8120

04864702

FPC8220

100

208

6.75

16

24

70

2472

04460402

FPC2120

04864802

FPC2220

240

04460502

FPC7120

04864902

FPC7220

277/480

2730

04460602

FPC4120

04865002

FPC4220

480

2472

04460702

FPC8140

04865102

FPC8240

200

208

6.75

24

30

88

3863

04460802

FPC2140

04865202

FPC2240

240

04460902

FPC7140

04865302

FPC7240

277/480

3914

04461002

FPC4140

04865402

FPC4240

480

3863

04461102

FPC8160

04865502

FPC8260

300

208

6.75

30

36

106

4223

04461202

FPC2160

04865602

FPC2260

240

04461302

FPC7160

04865702

FPC7260

277/480

4841

04461402

FPC4160

04865802

FPC4260

480

4223
