RPH Series Outdoor Rated Stainless Steel Electric Infrared Heater
MM Series “Mitey Midget” Electric Infrared Heater
FFH Series Electric Utility Infrared Heater
MountingPlate (provided)
on top center allows heater
to be mounted parallel or
angled using a standard
pipe nipple and box cover
(supplied by installer)
• Instant, high-intensity radiant heat, with 30° symmetric heat pattern.
• Listed for indoor spot heating and for outdoor unprotected applications.
• Specialized Ruby “Red” Quartz Lamp infrared heating element for glare reduction.
• Stainless Steel housing with Coilzak Aluminum reflector for good reflectivity & corrosion
resistance.
• Heating element and mounting plate included.
• Dimensions: 24” x 5-3/8” x 4-1/2.”
• Made in U.S.A.
MOUNTING CLEARANCES
RECOMMENDED MOUNTING HEIGHT
6” from ceiling
24” from vertical surface
72” from face of heater to combustible surface
RPH-208
8’-12’
RPH-240
8’-12’
Note: All MM-13A through MM-46A models are ETL Listed for use with Quartz Lamps Only!
Lamp voltage must match supply voltage.
Mounting Clearances
24” from ceiling & from vertical surface
24” from face of heater to combustible surface
36” from another heater
• Instant, high-intensity radiant heat, with 60° symmetric heat pattern.
• MM heaters excel as people-heaters in areas requiring a linear, compact & concentrated heat source.
• Listed for indoor industrial and commercial comfort heat applications.
• Heavy duty Aluminum extrusion with a bright
Aluminum insert for maximum reflectivity.
• Anodized Aluminum housing, (0.62” thick).
• Heat Element Sold Separately.
• Dimensions: 3.750” Wide x 3.380” High.
• Made in U.S.A.
MOUNTING CLEARANCES
3” from ceiling
24” from vertical surface
72” from floor
FFH-512A
FFH-912B
• Both FFH Series Heaters are excellent for Farrowing & Finishing applications.
• Both units feature an 8 ft. 18/3 grounded cordset to plug into any 120V service.
• Gold anodized Aluminum reflectors, with a 90° symmetrical reflector pattern.
• Compact housing design, with the following housing finish:
FFH-512A: Gold Anodized Finish
FFH-912B: Brown Enamel Finish
• Quartz Tubes Heat Element(s), Wire Guard & (2) 4’ ft. Jack Chains are included.
• FFH-912BOnly: Offers (2) On/Off toggle switches to operate heating elements independently.
• Listed for indoor industrial and
commercial comfort heat
• Made in U.S.A.
SIZING CHART - FFH SERIES
MOUNTING
HEIGHT
HEATER
MODEL LENGTH WIDTH COVERAGE
(Sq. Ft.)
WATTS
/ Sq. Ft.
6’
FFH-512A 7
6
42
13.1
FFH-912B 6
7
42
21.4
7’
FFH-512A 8
7
56
9.8
FFH-912B 7
8
56
16.1
8’
FFH-512A 9
8
72
7.6
FFH-912B 8
9
72
12.5
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MAX
WATTS
MAX
BTU'S
MAX
VOLTS PH UNIT
LENGTH
WT.
(LBS)
LIST
OPTIONAL WIREGUARDS
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
LIST
04440102
MM-13A
500
1707
120
1
13"
3
250
443906 MMWG-13
27
04495402
MM-24A 900 / 1600
5461
277
1
24"
5
270
441896 MMWG-24
51
04427202
MM-33A
2500
8533
600
1
33"
6
291
443920 MMWG-33
55
04420302
MM-46A 3000 / 3800
12457
600
1
46"
7
318
442046 MMWG-46
65
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS BTU’S VOLTS PHASE AMPS REPLACEMENT
QUARTZ LAMP
WT.
(LBS)
LIST
OPTIONAL WIREGUARD
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
LIST
08845039 RPH-208-A 1600 5,461 208
1 7.7
632-1620
5
366
08809902 RPHWG
38
08845139 RPH-240-A 1600 5,461 240
1 6.7
632-1624
5
MFG CATALOG
NUMBER
MFG MODEL
NUMBER WATTS BTU’S VOLTS PHASE AMPS REPLACEMENT
QUARTZ TUBE
WT.
(LBS)
Dimensions (in.)
LIST
Length Width Height
08838900
FFH-512A 550
1877
120
1
5
671-3492
4
22
5
3
239
08827814
FFH-912B 450/900 3072
120
1
8
671-3454
4
17
6
4
436
