OCH Series Outdoor / Indoor Rated Quartz Electric Infrared Heater
Features
• Frosted Quartz Tube heating element (included)
• Listed for suspended, totally exposed (outdoor) and indoor
spot heating applications
• Finish: High-temp brown powder coated finish or corrosion
resistant stainless steel 24 gauge housing
• 60° Symmetric Heat Pattern
• Gold anodized Aluminum reflector and end caps
• Painted models are direct wire, unless specified and are
supplied with 6” lead wires for field connection in the
internal wiring compartment. These models are available
with a factory installed 6’ cord set. The 208V model must
have a field supplied plug.
• Stainless steel models include an electrical enclosure
assembled to the end of the heater housing and (2) 6” long
lead wires for direct field connection.
• Two 2’ ft. long mounting chains and four S-Hooks included
• The OCH-Series can be surfaced mounted using the supplied
mounting brackets which allow up to a 45° horizontal tilt
adjustment.
• Made in U.S.A.
Product Models
Product Accessories
Heats solid objects, not the air!
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
FOR USE WITH
WT.
(LBS)
LIST
04808802
OCHWG-46
Stainless Steel Wire Guards
OCH-46 Series Models
2
61
04808902
OCHWG-57
OCH-57 Series Models
2
64
08811202
VMB-41-SS
Wall Mtg. Brackets (2)
ALL OCH Models
12
226
04459402
VHC-15
Variable Heat Controller
208/240V OCH Models Only
3
173
04853502
VHC-32
Variable Heat Controller
208/240V OCH Models Only
3
449
FINISH - BROWN
FINISH - STAINLESS Steel
CONNECTION
TYPE WATTS BTU’S VOLTS AMPS
Qtz. Tube
Repl.
Element
WT.
(LBS)
Includes Electrical Enclosure
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
LIST
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
LIST
04804402 OCH-46-120VE
335
04805202 OCH-46-120V-SSE
394
Hard Wire
1500 5120 120 12.5 671-3784
10
04804502 OCH-46-208VE
04805302 OCH-46-208V-SSE
2000 6826 208 9.6 671-5061
04804602 OCH-46-240VE
04805402 OCH-46-240V-SSE
2000 6826 240 8.3 671-3785
04804702 OCH-46-277VE
04805502 OCH-46-277V-SSE
2000 6826 277 7.2 671-5018
04804902 OCH-57-208VE
383
04805702 OCH-57-208V-SSE
436
3000 10239 208 14.4 671-5060
12
04804802 OCH-57-240VE
04805602 OCH-57-240V-SSE
3000 10239 240 12.5 671-3786
04805002 OCH-57-277VE
04805802 OCH-57-277V-SSE
3000 10239 277 10.8 671-5059
04805102 OCH-57-480VE
04805902 OCH-57-480V-SSE
2250 7679 480 4.7 671-5058
04859702 OCH-46-120VCE
362
---
---
---
Corded
1500 5120 120 12.5 671-3784 11
04859802 OCH-57-208VCE
425
---
---
---
2000 6826 208 9.6 671-5060
13
04859902 OCH-57-240VCE
---
---
---
2000 6826 240 8.3 671-3786
