Industrial Direct Drive Exhaust Fans
Features
• Totally enclosed motors:
- 1-Phase motors are field convertible 115V / 230V
- 3-Phase motors are field convertible 230V / 460V
- Motors are set to lower voltage at the factory, unless a
request is made at time of order to set to the higher voltage
• 14 gauge steel venturi with steel pipe bracing
• 4-blade steel propeller
• 1 year limited warranty
Options
• CES Shutters
• EMF Front Guards
• IBG Rear Guards
Note: Depth dimension varies with motor selection.
Dimensions
Standard Models
SIZE
BLADE DIAMETER
PANEL SIZE
DEPTH DIMENSION
12”
12”
16”
11”
16”
16”
20”
11”
20”
20”
24”
13”
24”
24”
30”
15”
30”
30”
36”
15”
36”
36”
42”
18”
42”
42”
48”
18”
48”
48”
54”
20”
Note: Products listed in this section are custom built and subject to 100% cancellation/restocking charges.
BLADE
SIZE
MFG MODEL NUMBER
PANEL
SIZE (Sq.)
HP
RPM CFM
0” SP
db’s
@ 10’
WT.
(LBS)
LIST
1-PHASE
3-PHASE
TEC
115/230V-60Hz 230/460v-60Hz
1 PH 3 PH
12”
IED12-1/4
IED12-1/4-3
16”
1/4
1725
1480
64
30
1297
1302
16”
IED16-1/3
IED16-1/3-3
20”
1/3
1725
2834
73
40
1553
1584
18”
IED18-1/2
IED18-1/2-3
24”
1/2
1725
3890
74
55
1745
1759
20”
IED20-3/4
IED20-3/4-3
24”
3/4
1725
4574
77
65
2027
2027
24”
IED24-1
IED24-1-3
30”
1
1725
6632
81
155
2339
2213
30”
IED30-1
IED30-1-3
36”
1
1150
8600
79
185
4580
2650
36”
IED36-1 1/2
IED36-1 1/2-3
42”
1.5
1150
12103
82
260
5772
3547
42”
------
IED42-2-3
48”
2
1150
17315
87
280
--
3802
48”
------
IED48-3-3
54”
3
850
24280
86
360
--
5329
