Infrared Heat Coverage Comparision
FSS-95
MR-13
(Discontinued)
FSS Series Heavy Duty Flat Panel Emitter Electric Overhead Infrared Heater
Heavy Duty Overhead Infrared Heaters for Indoor Spot Heating, Zone or Total Area
Heating Applications
FSS-14
Standard Models
• High-Density medium wave radiant heat, with 60°
symmetric heat pattern.
• Approximately 78.5% efficient vs 50% efficiency
of metal sheath elements.
• More uniform heat pattern than metal sheath.
• Rugged flat panel emitter, great for high vibration
areas.
• Gold anodized Aluminum housing for efficient,
long term reflectivity & corrosion resistance.
• Single or three phase wiring on select models.
• ”L” brackets included for chain suspension, or rigid
mounting.
• Field wiring box mounted on each heater.
• Heavy duty wire guard factory installed.
• 25,000 hour element life expectancy.
• Shipped fully assembled
• Made in U.S.A.
FSS-31
FSS-43
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS VOLTS PHASE BTU’s /
Hr.
AMPS
ELEMENTS
PER HEATER
WT.
(LBS)
LIST
FSS Replacement Elements
LIST
1-PH 3-PH
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
04881502 FSS-1412-1
1450
120
1
4947
12.1
1
7
830
01356002
64337-001
590
04881602 FSS-1420-1
208
1
6.97
01356102
64337-002
04881702 FSS-1424-1
240
1
6.04
01356202
64337-003
04881802 FSS-1427-1
277
1
5.23
01356302
64337-004
04881902 FSS-1448-1
480
1
3.02
01356402
64337-005
04882002 FSS-1457-1
600
1
2.52
01356502
64337-006
04882102 FSS-3120-1
3150
120
1
10,748
15.14
13
1030
01356602
64337-007
689
04882202 FSS-3124-1
240
1
13.13
01356702
64337-008
04882302 FSS-3127-1
277
1
11.37
01356802
64337-009
04882402 FSS-3148-1
480
1
6.56
01356902
64337-010
04882502 FSS-3157-1
600
1
5.48
01357002
64337-011
04882602 FSS-4320-3
4300
208 1 or 3
14,672
20.67 11.94
18
1260
01357102
64337-012
863
04882702 FSS-4324-3
240 1 or 3
17.91 10.36
01357202
64337-013
04882802 FSS-4327-1
277
1
15.52
01357302
64337-014
04882902 FSS-4348-3
480 1 or 3
8.96 5.18
01357402
64337-015
04883002 FSS-4357-3
600 1 or 3
7.48 4.32
01357502
64337-016
04883102 FSS-9520-3
9500
208 1 or 3
32,414
45.67 26.39
31
1860
01357602
64337-017
910
04883202 FSS-9524-3
240 1 or 3
39.6 22.89
01357702
64337-018
04883302 FSS-9527-1
277
1
34.3
01357802
64337-019
04883402 FSS-9548-3
480 1 or 3
19.8 11.44
01357902
64337-020
04883502 FSS-9557-3
600 1 or 3
16.5 9.54
01358002
64337-021
04883602 FSS95TMK
TANDEM MOUNTING KIT
6
650
