Hydronic & Architectural Electric Baseboard Heater Accessories
Field Installed Accessories
Baseboard Sections
Wireway Covers (White Units Only)
Dimension
OUTSIDE
CORNER
INSIDE
CORNER
Outside and inside corner
sections are 6” on longest side
DESCRIPTION
Standard White Commercial Brown
LIST
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
Single Pole, In-Built T-Stat, 22A@ 120-240V; 18A@ 277V;
0°-110° F
01118702 3900T1 01119502 3900T1C
67
Double Pole, In-Built T-Stat, 22A@ 120-240V; 18A@ 277V;
0°-110° F
01118802 3900T2 01119602 3900T2C
86
Air Conditioning Receptacle Section, 20 Amp @ 125-277V 01118902 3900AC 01119902 3900ACC
79
120V. Receptacle Section, 15 Amp
01119002 3900REC 01120002 3900RECC
74
Disconnect Switch, 20 Amp @ 125-277VAC; DPST
01119402 3900DS 01120402 3900DSC
108
STANDARD WHITE COMMERCIAL BROWN
DESCRIPTION
LIST
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MFG
CATALOG
NUMBER
MFG MODEL
NUMBER SECTION SIZE
01121502
39BS28
0112215
39BS28C
Blank Section
28”
233
01121602
39BS36
0112222
39BS36C
36”
278
01121702
39BS48
0112239
39BS48C
48”
343
01121802
39BS60
0112246
39BS60C
60”
411
01121902
39BS72
0112253
39BS72C
72”
474
01122002
39BS96
0112260
39BS96C
96”
610
01150902
39BS120
0115100 39BS120C
120”
813
01119102 3900-ICS 0112017 3900-ICSC Inside Corner
-
134
01119202 3900-OCS 0112024 3900-OCSC Outside Corner
136
01119302
3900-CS 01120302 3900-CSC Control Section 4” Blank
170
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
LENGTH WT.
(LBS)
LIST
01122802 3900WW28
28”
2
52
01122902 3900WW36
36”
2.5
57
01123002 3900WW48
48”
3.5
68
01123102 3900WW60
60”
4.5
75
01123202 3900WW72
72”
5.5
80
01123302 3900WW96
96”
7.5
105
01151102 3900WW120 120”
7.5
141
