Custom Specified Models
Note: Amps include motor Amp loads.
Note: Products listed in this section are custom built and subject to 100% cancellation/restocking charges.
Note: Please see page 60 for custom color availability - add 10% to net heater cost.
LENGTH
KW Elements per
Heat Deck
CFM
1-PHASE UNITS - AMPS (HIGH)
3-PHASE UNITS - AMPS (HIGH)
LIST
208V 240V 277V 600V 208V 240V
480V
600V
High Low Left
Right High Low
3-WIRE
33”
2
1
2
250 230
10.6
9.3
8.12
3.8
9.2
8.1
4.1
3.3
2668
3
2
3
15.4
13.5
11.7
5.5
9.2
8.1
4.1
3.4
2748
4
2
4
20.2
16.7
15.3
7.2
13.4
11.8
6
6.22
2857
5
3
5
25
21.8
19
8
17.6
15.4
7.8
5.5
2986
6
3
6
29.9
26
22.6
10.5
17.6
15.4
7.8
6.3
3115
46”
4
2
2
500 460
21.1
18.6
16
7.46
18.7
16.2
8.1
6.5
3040
6
4
3
30.8
26.9
23.1 10.79 18.4
16.2
8.1
6.5
3176
8
4
4
40.4
35.2
30.5 14.12 26.7
23.4
11.7
9.4
3322
10 6
5
50
43.6
37.7
17.5
35.1
30.7
15.4 12.3
3457
12 6
6
59.6
51.9
44.9
20.8
35.1
30.7
15.4 12.3
3528
66”
6
3
2
2
750 690
31.8
27.9
24.1
11.3
27.6
24.3
12.3
9.8
3865
9
6
3
3
46.2
40.4
35
16.3
27.6
24.3
12.3
9.9
4023
12 6
4
4
60.6
52.9
45.8
21.3
40.1
35.2
17.7 15.6
4179
15 9
5
5
75
65.4
56.7
25.5
52.6
46.1
23.1 15.7
4324
18 9
6
6
89.4
77.9
67.5
31.3
52.6
46.1
23.1 18.5
4480
79”
8
4
2
2
1000 920
42.3
37.1
32
14.9
36.7
32.3
16.2
13
4324
12 8
3
3
61.5
53.8
46.5
21.6
36.7
32.3
16.2
13
4418
16 8
4
4
80.7
70.5
61
28.2
53.4
46.8
23.5 18.8
4587
20 12
5
5
NA 87.1
75.4
34.9
70.1
61.4
30.7 24.6
4660
24 12
6
6
NA NA 89.8
41.6
70.1
61.4
30.7 24.6
4745
HOW TO DESIGNATE A MODEL:
Series Number
Cabinet Size
33=33” 46 = 46” 66 = 66” 79 = 79”
Element KW
2KW through 24KW
See model chart for length and KW options.
Element Voltage
20 = 208V 24 = 240V 27 = 277V
41 = 415V 48 = 480V 57 = 600V
Phase
1 = Single Phase 3 = Three Phase
Number of Wires in Electrical Service
2 or 3
Control Options
B3, B4, B5, B6
(see control options chart)
Motor Fusing Option
M = Required O = Not Required
Disposable Filter Option
F = Required O = Not Required
Summer Fan Switch
S = Included O = Not Included
Disconnect Option
C = Circuit Breaker D = Disconnect Switch
Air Flow Con guration
A = Bottom in / Top out B = Bottom in / Front out
D = Front in / Front out
C = Front in / Top out
O = None
63 46 D 08 24 1 2 B3 S D O F
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Step 8
Step 9
Step 10
Step 11
Step 12
6300 Series Multiple Angle Cabinet Unit Heater
