20 / 117
20
Diffuser Descriptions
Standard Heater
Anemostat Diffuser
Radial Louvered Cone Diffuser
Linear Louvered Diffuser
For general distribution.
Choice of other diffusers
may be added after
installation if required.
O.S.H.A guard for
fan blade D1604 for
2605-2620, & D1614 for
2625-2650 Do not use
with other diffusers.
With vanes vertical, straightens air for higher
mounting. Closed position for broad horizontal
coverage. Adjustable for intermediate
requirements.
Affords more precise directional
throw where heaters cannot be
mounted directly over area to be
heated or for heating long narrow
areas.
Blends room air with
heated air for widespread
distribution without
excessive drafts.
MODEL
MODEL
MODEL
DIM: A
DIM: A
DIM: A
DIM: B
DIM: B
DIM: B
MODEL
MAX
MOUNTING
HEIGHT*
MAX
MOUNTING
HEIGHT
MAX
MOUNTING
HEIGHT
MAX
MOUNTING
HEIGHT
MAX
MOUNTING
HEIGHT
VERTICAL
45 DEGREES OPEN
D
(ft.)
D
(ft.)
D
(ft.)
D
(ft.)
L
(ft.)
W
(ft.)
2605
2607
2610
2615
2620
2625
2630
2640
2650
10
10
22
20
18
32
30
26
24
25
25
40
44
48
48
60
64
68
15
15
26
24
22
38
36
32
28
25
25
36
38
40
42
50
50
50
8
8
15
14
13
24
22
20
18
30
30
44
46
50
70
74
78
82
10
10
22
20
18
34
32
30
28
10
10
14
14
15
30
34
36
40
40
40
54
60
66
80
80
90
100
9
9
20
18
16
30
28
26
24
25
25
38
40
42
60
64
67
70
*Minimum mounting height 6 feet.
**Dimensions are for all heater models without a diffuser option. Adding a diffuser will change the vertical (”A”) dimension of heater.
All mounting distances are in feet. All diagrams show optional mounting bracket.
D1600
D1610
KW
5-20
25-50
KW
5-20
25-50
KW
5-20
25-50
6 1/2"
11 1/2"
14 1/4"
24 3/4"
D1602
D1612
6"
6"
16 1/4"
22 1/4"
D1603
D1613
7"
9 3/4"
19 1/4"
29 3/4"
B
A
B B
A
B
A
D'
L'
W'
D'
D'
B
A
B
KW
5-20
25-50
B
20 1/2”
27”
A
15”
21 1/2”
Dimensions**
2600 Series Downflow Unit Heater
General Description & Diffuser Information
CONSTRUCTION:
• 16 gauge steel cabinet with epoxy powder coated finish and control compartment with a hinged and
latched access door.
• OSHA guards standard with all models.
• Made in U.S.A
HEATING ELEMENT:
• Corrosion resistant element with steel sheath and steel spiral fins.
OVERHEAT PROTECTION:
• All units come equipped with manual reset limit controls to de-energize the heater should an
over-temperature situation occur.
FAN and MOTOR:
• Totally enclosed, 1 speed, 1 phase permanently lubricated, thermally protected
motors with unit bearings on 3KW - 20KW models. Totally enclosed, 2 speed,
1 phase permanently lubricated, thermally protected motors with sleeve bearings
on 24KW - 50KW models.
• Axial flow fan blade - 1570 RPM max.
• All models equipped with fan purge which allows fan to operate after
elements are de-energized to purge residual heat.
TEMPERATURE CONTROLS:
• 208V, 240V, 277V and 480V units have In-Built 24 Volt transformer for low
voltage remote thermostat application.
• 600V units have In-Built 240V control on 5-20 KW models, 25-50 KW models have
24V control.
• 25 KW - 50 KW models may operate as 2 stage heaters if 2 stage remote thermostat is used.
DISCONNECT SWITCH:
• All models equipped with In-Built disconnect except F3F2640, F3F2650 and H3H2650.
INSTALLATION:
• Unit can be mounted using optional mounting bracket or field constructed angle iron bracket.
• Not recommended for mounting with threaded rod or chain.
2600 Series shown with
standard wire guard.
Diffusers are field installed.
