Product Specifications
CABINET & CONSTRUCTION:
Shall be constructed of 20 gauge rigid steel with baked on epoxy
powder coat paint for durability. Made in U.S.A.
DISCHARGE VANES:
Shall extend the entire width of the unit and be adjustable for optimum
performance of air flow.
BLOWERS:
Shall be forward curved centrifugal type, DWDI with corrosion resistance scroll
and wheel.
MOTORS:
Shall be heavy duty, PSC, direct drive high efficiency and designed for use with
SCR controllers.Motors shall be permanently lubricated for long life and have thermal over load
protection. Motor shall have
double insulation protection
for quieter operation. Quick
disconnects shall be supplied
to
accommodate
easy
installation and service of
motor.
SCR SPEED CONTROLLER:
Supplied
on
all
units
compatible with the motor
with low end adjustment for
air volume control and savings
in power consumption.
ELECTRICHEAT(OPTIONAL):
Electric heater available as
field installed option. Electric
heater shall be steel sheath
element with helical wound
steel fins for maximum heat
transfer and safety.
Air Curtain with Heater
Module
NOTE: All heating sections
are constructed of totally
enclosed fin tubular
elements for safety and
longer operating life. With
heating section installed,
unit becomes a 24 Volt
control unit and can utilize
a low voltage thermostat for
control of heating.
NOTE: For 72” through
120” units, order
multiple heater modules
corresponding to the actual
air curtain models
CF-C Series TPI Commercial Air Curtains
CF & CFH Series Variable Speed Air Curtains
• Super thin body, full metal housing
• Cross flow, 2-speed fans
• Adjustable air deflector
•Mechanical control
• Units are 120V at 60Hz
Features
Standard Models
EXAMPLE
Use the example shown (left) to order unit with heat section by
specification
Model # Unit Width KW Volts Phase
CFHTR 36
10.0 208
3
|
|
|
|
|
MFG
MODEL
HEATER
WIDTH KW VOLTS PHASE HEATER
AMPS
MINIMUM CIRCUIT
AMPS
MAXIMUM
FUSE AMPS BTU/H 75°C WIRE
AWG
LIST
CFHTR
36, 48, or 60 Inch Width
NOTE: 12KW MAXIMUM ON 36” WIDTH UNITS
3
208
3
8.3
10.4
15
10,239
14
36” - 1280
48” - 1413
60” - 1462
240
7.2
9.0
15
14
480
3.6
4.5
15
14
277
1
10.8
13.5
15
14
208
14.4
18.0
20
12
240
12.5
15.6
20
12
5
208
3
13.8
17.25
20
17,075
12
240
12.0
15.0
20
12
480
6.0
7.5
15
14
277
1
18.0
22.5
25
10
208
24.0
30.0
35
8
240
20.8
26.6
30
10
7.5
208
3
20.8
26.0
30
25,597
10
240
18.0
22.5
25
10
480
9.0
11.3
15
14
277
1
27.0
33.8
40
8
208
36.0
45.0
50
6
240
31.2
39.0
45
8
10
208
3
27.7
34.4
40
34,130
8
240
24.0
30.1
35
8
480
12.0
15.0
20
12
277
1
36.1
45.1
50
6
240
41.6
52.0
60
6
12
208
3
33.3
41.6
45
40,956
8
240
28.8
36.0
40
8
480
14.4
18.0
20
12
277
1
43.3
54.1
60
6
15
208
3
41.6
52.0
60
51,195
6
240
36.0
36.0
55
6
480
18.0
18.0
30
10
MFG
CATALOG
NUMBER
SIZE
(in)
MFG
MODEL
NUMBER
FT. / MIN.
HI - LOW
NOZZLE
CFM VOLTS RPM
HI - LOW
AMPS
HI - LOW
WATTS
HI - LOW
WT.
(LBS)
LIST
STANDARD UNITS: 1/2 HP MODELS - UP TO 10’ HIGH DOORWAYS - WITHOUT HEAT SECTION
06712002 36
CF36
3288/455 2672/333
120
1659/620
3.9/3.4
472/154
74
1673
06712102 48
CF48
4168/786 4515/766
1606/583
4.4/3.6
519/189
82
1814
06712202 60
CF60
4168/764 6544/931
1636/562
4.4/3.8
509/199
90
1956
72 2 EA: CF36 3288/455 5344/666
1659/620
7.8/6.8
944/308 148
3249
96 2 EA: CF48 4168/786 9030/1532
1606/583
8.8/7.2
1038/378 164
3521
108 3 EA: CF36 3288/455 8016/999
1659/620
11.7/10.2 1416/462 222
4874
120 1 EA: CF48 4168/786 9859/1432
1606/583
12.2/10.4 1982/497 230
5009
2 EA:CF36 2672/333
1659/620
HEAVY DUTY UNITS: 3/4 HP MODELS - UP TO 12’ HIGH DOORWAYS - WITHOUT HEAT SECTION
06712302 36
CFHD36
3288/1120 2672/819
120
1689/603
4.4/4.3
603/192
77
1761
06712402 48
CFHD48
4256/929 4611/906
1662/500
5.9/4.8
586/168
85
1902
06712502 60
CFHD60
4256/924 5763/1126
1652/509
5.2/4.4
708/172
93
2048
72 2 EA: CFHD36 3288/1120 5344/1638
1689/603
8.8/8.6
1206/384 154
3419
96 2 EA: CFHD48 4256/929 9222/1812
1662/500
11.8/9.6 1172/336 170
3693
108 3 EA: CFHD36 3288/1120 8016/2457
1689/603
13.2/12.9 1809/576 231
5128
120 1 EA: CFHD48 4256/929 9955/2544
1662/500
14.7/13.4 2981/552 239
5264
2 EA: CFHD36 3288/1120
1689/603
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS
CFM
FPM NOISE LEVEL (dB)
DIMENSIONS WT.
(LBS)
LIST
HIGH LOW HIGH LOW HIGH LOW “L” “W” “H”
08764402 CF35-C 300 1177 942 2560 1968
67
65
35”
8-3/4” 10-1/4”
33.1
400
08764502 CF47-C 350 1648 1295 2560 1968
69
67
47”
43
464
08764602 CF59-C 400 2119 1648 2560 1968
71
69
59”
48.5
555
