PD Series Packaged Duct Heater
Standard Features
• Galvanized Steel Element Rack - Always 1”
shorter than duct height and 1/2” shorter than
duct width to allow insertion clearance
• Galvanized Steel Compartment with 1/2”
fiberglass Insulation & Hinged Cover
• Door Interlock Disconnect Switch
• Primary Automatic Reset Temp Limiting Control
• Load Carrying Secondary over Temperature
Protective Device(s)
• Definite Purpose Magnetic Contactor(s)
• Differential Pressure Fan Inter-lock Switch
• Step Down Control Transformer / 24 Volt
• Permanently Attached Wiring Diagram on
inside of Terminal Compartment Cover
• Made in U.S.A.
Standard Models
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
KW
POWER
VOLTS/
PHASE
DUCT
WIDTH
W
DUCT
HEIGHT
A
DIMENSIONS
AMPS CONTROL
STEPS
WT.
(LBS)
LIST
C E M
06170002
PD5-128-1
5
240-1
12
8
4.75 6.5
26
20.9
1
22
828
06170102
PD10-1810-1
10
18
10
4.75 6.5
28
41.7
2
37
1111
06170202
PD15-1812-1
15
18
12
4.75 6.5
27
62.5
2
33
1299
06170302
PD20-2012-1
20
20
12 9.125 7.5
31
83.3
2
37
1630
06170402
PD25-2016-1
25
20
16 9.125 7.5
38
104.2
3
56
2598
06170502
7PD2-128-1
2
277-1
12
8
4.75 6.5
26
7.2
1
21
828
06170602
7PD3.5-128-1
3.5
12.6
852
06170702
7PD5-128-1
5
18.1
1092
06170802
8PD5-128-3
5
208-3
12
8
4.75 6.5
26
13.9
1
22
954
06170902 8PD10-1810-3
10
18
10
4.75 6.5
22
27.8
1
27
975
06171002 8PD15-1812-3
15
18
12 9.125 6.5
25
41.7
1
32
1136
06171102 8PD15-1812-2-3 15
18
12 9.125 6.5
28
41.7
2
34
1193
06171202 8PD20-2012-3
20
20
12 9.125 6.5
40
55.6
2
39
1441
06171302 8PD25-2016-3
25
20
16 9.125 6.5
29
69.5
2
58
1454
06171402 8PD30-2416-2-3 30
24
16 9.125 7.5
29
83.4
2
65
2068
06171502 8PD30-2416-3
30
24
16 9.125 7.5
35
83.4
3
60
2102
06174302 8PD35-2416-3
35
24
16 9.125 7.5
35
97.3
3
65
2244
06173202 8PD40-2416-3
40
24
16 9.125 7.5
43
111.2
3
75
2834
06173302 8PD45-3016-3
45
30
16 9.125 7.5
43
125.1
3
80
2893
06173402 8PD50-3016-3
50
30
16 9.125 7.5
43
139
3
85
2951
06171602
PD-128-3
5
240-3
12
8
4.75 6.5
26
12.1
1
21
803
06171702
PD10-1812-3
10
18
10
4.75 6.5
22
24.1
1
26
887
06171802 PD15-1812-1-3
15
18
12
4.75 6.5
20
36.2
1
30
993
06171902 PD15-1812-2-3
15
18
12 9.125 6.5
26
36.2
2
33
1016
06172002
PD20-2012-3
19.9
20
12 9.125 6.5
28
47.9
2
39
1299
06172102
PD25-2016-3
25
20
16 9.125 6.5
39
60.2
2
57
1454
06172202 PD30-2416-2-3
30
24
16
4.75 6.5
25
72.3
2
57
1607
06172302 PD30-2416-3-3
30
24
16 9.125 6.5
35
72.3
3
65
1678
06173502
PD35-2416-3
35
24
16 9.125 7.5
35
84.3
3
65
1866
06173602
PD40-2416-3
40
24
16 9.125 7.5
35
96.3
3
75
2149
06173702
PD45-3016-3
45
30
16 9.125 7.5
43
108.4
3
80
2787
06173802
PD50-3016-3
49.8
30
16 9.125 7.5
43
120
3
85
2905
06172402
4PD5-128-3
5
480-3
12
8
4.75 6.5
26
6.1
1
21
922
06172502 4PD10-1810-3
10
18
10
4.75 6.5
22
12.1
1
26
975
06172602 4PD15-1812-3
15
18
12
4.75 6.5
20
18.1
1
30
1028
06172702 4PD15-1812-2-3 15
18
12 9.125 6.5
26
18.1
2
34
1182
06172802 4PD20-2012-3
20
20
12 9.125 6.5
26
24.1
2
39
1207
06172902 4PD25-2016-3
25
20
16 9.125 6.5
22
30.1
2
58
1242
06173002 4PD30-2416-2-3 30
24
16
4.75 6.5
18
36.2
2
65
1276
06173102 4PD30-2416-3-3 30
24
16 9.125 6.5
24
36.2
3
65
1347
06173902 4PD35-2416-3
35
24
16 9.125 6.5
26
42.2
3
65
1725
06174002 4PD40-2416-3
39.9
24
16 9.125 6.5
40
48.1
3
75
1949
06174202 4PD50-3016-3
50
30
16 9.125 6.5
36
60.2
3
85
2361
