Hotpod
™
Supplemental Duct Mounted Heating System
• Use to heat cold rooms or additions without upgrading central
system
• Fan only operation for increased cfm output for A/C cycles
• 6" 1000/500 Watt and 8" 1440/720 Watt models available
• Two stage operation
• 120V corded and hard wire models available
• 10' Cord length on corded models
• Zero clearance for all models
• All models include UT8003 low voltage thermostat
• Optional wireless thermostat
• Silent boot option available for rigid duct applications
HotPod - Features
Standard HotPod Models
Multi-Pak Models - Includes 4 Hotpods
Note: Multi-Pak specifications (watts, volts, etc) are for each individual hotpod in the pack excluding weight.
6” Hotpod
8” Hotpod
Note: Silent Boot can only be used with rigid duct work
Patented
Patent No. 8,285,127
*includes 1 HotPod display
Standard Silent Booster Models
6” Silent Booster
8” Silent Booster
Silent Booster - Features
• 120V corded and hardwire models available
• Adds 120 CFM Boost to duct heating or ventilation applications
• Can utilize optional TPI SilentBoot™ for whisper quiet operation in
rigid duct application.
• 14” of duct, 4’ from register is all that is needed for installation
• Optional wireless thermostat can be utilized to control Silent
Booster™ to increase room comfort
Silent Booster
™
Supplemental Duct Mounted Boosting System
Moisture Control System - Features
• 120V, 8” Ducted Booster Fan; De-humidistat included
• 6” to 8” adapters available
• Includes all ductwork and outside damper
• Uses Heavy Duty booster fan to eliminate humidity from
basements, crawl spaces, or damp areas.
UPC#
686334
MODEL
DESCRIPTION
WATTS VOLTS MIN.CIRC.
SIZE (AMP)
TEMP
RISE (F) WT RPM CFM NEMA
PLUG
DIMENSION
L X W X H
290074 HP6-1000120-2T
6” INLET, HARDWIRE 1000/500 120
8.33
26 4 1500 130 NA 10 1/2 x 8 1/2 x 6
290043 HP6-1000120-2CT 6” INLET, WITH CORD SET 1000/500 120
8.33
26 4 1500 130 5-15P 10 1/2 x 8 1/2 x 6
290081 HP8-1440120-2T
8” INLET, HARDWIRE 1440/720 120
12.6
23 6 1500 210 NA 11 x 10 1/2 x 8
290067 HP8-1440120-2CT 8” INLET, WITH CORD SET 1440/720 120
12.6
23 6 1500 210 5-15P 11 x 10 1/2 x 8
UPC#
686334
MODEL
DESCRIPTION
WATTS VOLTS MIN.CIRC.
SIZE (AMP)
TEMP
RISE (F)
WT.
LBS RPM CFM NEMA
PLUG
DIMENSION
L X W X H
290036 HP6-1000120-2T 4 PACK 6” INLET, HARDWIRE 1000/500 120
8.33
26 16 1500 130 NA 10 1/2 x 17 x 12
290111 HP6-1000120-2CT 4 PACK 6” INLET, WITH CORD SET 1000/500 120
8.33
26 16 1500 130 5-15P 10 1/2 x 17 x 12
290050 HP8-1440120-2T 4 PACK 8” INLET, HARDWIRE 1440/720 120
12.6
23 25 1500 210 NA 10 1/2 x 20 x 16
290128 HP8-1440120-2CT 4 PACK 8” INLET, WITH CORD SET 1440/720 120
12.6
23 25 1500 210 5-15P 10 1/2 x 20 x 16
290333 HP6H-12PK* 12 PACK 6” INLET, HARDWIRE 1000/500 120
8.33
26 58 1500 130 NA 21 x 14 1/2 x 43
290340 HP6C-12PK* 12 PACK 6” INLET, WITH CORD SET 1000/500 120
8.33
26 58 1500 130 5-15P 21 x 14 1/2 x 43
290357 HP8H-12PK* 12 PACK 8” INLET, HARDWIRE 1440/720 120
12.6
23 82 1500 210 NA 27 1/4 x 14 1/2 x 52
290364 HP8C-12PK* 12 PACK 8” INLET, WITH CORD SET 1440/720 120
12.6
23 82 1500 210 5-15P 27 1/4 x 14 1/2 x 52
UPC#
686334
MODEL
DESCRIPTION
VOLTS MIN.CIRC.
SIZE (AMP) WT RPM CFM NEMA
PLUG
DIMENSION
L X W X H
290371
SB6-120-T
6” SILENT BOOSTER (Hardwire)
120
15
4 1500 130 NA 10 1/2 x 8 1/2 x 6
290388
SB6-120-CT 6” SILENT BOOSTER (w/Cord Set)
120
15
4 1500 130 5-15P 10 1/2 x 8 1/2 x 6
290395
SB8-120-T
8” SILENT BOOSTER (Hardwire)
120
15
4 1500 210 NA 11 x 10 1/2 x 8
290401
SB8-120-CT 8” SILENT BOOSTER (w/Cord Set)
120
15
4 1500 210 5-15P 11 x 10 1/2 x 8
MOISTURE CONTROL SYSTEM
290418 MCS120-8CT 8” MOISTURE CONTROL SYSTEM 120
15
4 1500 210 5-15P 11 x 10 1/2 x 8
