Thermostats & Controls
Round - Low Voltage
Features
• Does not contain Mercury
• Dimensions 3-11/16” diameter
• Heat only for 24V heating systems
• White color • Temperature range - 50
o
- 90
o
F
Low Voltage Programmable Thermostats
Features
• 7 Day, 4 Settings Per Day
• Pre-Programmed or Custom Settings
• Control Accuracy +/- 1
o
F of Setpoint Temp
• Backlit Display, Energy Star Compliant
TH147-P
TH115-A-024T
Standard Models
Standard Models
Features
• 7 Day, 4 Settings Per Day
• Pre-Programmed or Custom Settings
• Control Accuracy +/- 1
o
F of Setpoint Temp
• Backlit Display, Energy Star Compliant
Standard Models
2 Stage Low Voltage Thermostat
Standard Models
Features
• 24V single or 2 stage heat and cool
• Gas, oil, or electric with air conditioning.
• Heat only, Heat only with fan, Cool only.
• Battery only, common wire only or common wire with battery
backup.
• System settings - Heat, Off, Cool, Auto, Emergency Heat.
• Temperature range - Heat 40-90
o
F, Cool 50-99
o
F.
• Dimensions: 3-9/16” H x 5-13/16” W x 1-1/2” D
TW123
UPC#
686334 MODEL
DESCRIPTION
VOLTAGE
MAX AMP
260008
A6176
Heat/Cool
24 VAC
1.0
UPC#
686334 MODEL
DESCRIPTION
523400 TH115-A-024T
Heat Only
Temp Range:40-86
O
F
Dims:4.89”H x 2.79”W x .91”D
UPC#
686334 MODEL
DESCRIPTION
523585 TH147-P
7 Day, 4 Settings per Day, Heating/Cooling, 1 Stage Heat/Cool
Temp Range Heat:41-82
O
F, Cool:59-95
O
F
Dims: 5”W x 3”H x 1”D,
UPC#
686334
MODEL
VOLTAGE
TEMP
RANGE
MAX
AMP
691116 TW123 / TH5220D 750MV - 2DV
40-90 Heat
50-99 Cool
1.0
