Thermal Area Treatment Heaters
APPLICATIONS:
The "TAT" series is designed to heat small and mid-sized rooms up to 150
o
F
. This provides effective portable
heating to areas infected with insects. It kills adult insects and will dehydrate larvae and eggs, making them unable
to hatch. Although chemical sprays only target adult insects, they can be used before utilizing the "TAT" system in
order to kill the adult insects.
The system is designed to bring the temperature up to 150
o
F
in one hour or less, if all preliminary requirements are
met.
• The "TAT" system may be used for water remediation, as well, in combination with adequate ventilation. Specific
models for water remediation are also available.
TAT BASE UNIT:
• Heavy duty stainless steel spiral fin heating elements
High temperature, ball bearing 1/3 HP - 1075 RPM blower motor
Forward curved centrifugal blower-900 CFM of air output
• Safety devices include airflow switch, disconnect switch, automatic limit control and manual reset limit control for
secondary protection
50 Amp unit may be linked to a 30 Amp unit to provide heating for larger spaces.
Timer/Temp controller may be used to control both units but must use the 50 Amp base unit as the master.
SUPPLEMENTAL TAT CONVECTORS
3 convectors are an integral part of each TAT system
120 Volt, 15 Amp (Standard wall plug) - 5120 BTU size
Supplied with 25' prewired cable that connects them to the TAT base unit control section with a three pin connector
If used in front of windows or large glass doors, they will reduce heat loss and provide more even heating
TIMER/TEMPERATURE CONTROL UNIT
Timer/Temp Controller is an integral part of the TAT system
24 Volt control device that controls the heat output of the TAT base unit and up to three TAT convectors for an
operating range of 120 - 150
o
F
and for a time period of 1 -10 hours after the preset temperature is reached
Supplied with a 25' prewired cable that connects to the TAT base unit control section using a four pin connector
Mounts on Door outside the area being treated.
LED lights will indicate when treatment is complete
Product Specifications
Heavy duty industrial construction
Forward curved centrifugal blower
High Temperature ball bearing motor
• Optional replaceable filter
Single point power connection
24 volt control
• Heavy duty spiral finned elements constructed of stainless steel
• Safety devices include airflow switch, automatic limit control and manual reset limit control for secondary protection
Disconnect switch and Unit Mounted Thermostat with range of up to 120 to 150
o
F
The “TAT” series is sold as a system that includes the base unit, three supplemental units and the remote
timer/ temperature control (supplemental units may be purchased separately if necessary)
Product Features
Sizing formula for TAT Series heaters: 50
Watts of heat per square foot of heated space
or 50W/sq ft.
Example: An 800 square foot structure will
require 40,000 Watts of heat to obtain 150
degrees of prolonged heat to be effective.
(800 sq ft x 50 Watts per square foot = 40,000
Watts of heat or 40KW of heat)
